Lưu ý: Màn hình không hỗ trợ cảm ứng
- LCD size: 2.0 inch (Diagonal)
- Display mode: Normally black
- Resolution: 240(H)RGB x 320(V)
- Dot pitch: 0.1275 (H) x 0.1275 (V) mm
- Active area: 30.6(H) x 40.8(V) mm
- Module size: 35.7(H) x 51.2(V) x 2.2(D) mm
- Color arrangement: RGB Vtertical stripe
- Interface: 4 Line SPI
- Driver IC: ST7789VW
- Luminance (cd/m2): 400 (TYP)
- Viewing Direction: All view
- Blacklight: 4 White LED
- Operating Temp: -20°C ~+ 70°C
- Storage Temp: -30°C ~+ 80°C
- Weight: TBD
